Gas Treatment Sic DPF Cordierite Diesel Particulate Filter

Beihai Xiaoming International Import and Export Trading Co., Ltd.
  • Body Material：Ceramic
  • Discharge Standard：Euro IV
  • Certification：ISO9001
  • Component：Catalytic Converter
  • Size：190*200mm, 224*305mm, 130*320mm etc
  • Cell：100-400cpsi

Base Info

  • Model NO.：DPF
  • Usage：as Catalyst Used in Diesel Engine
  • Transport Package：Wooden Box,Carton Box with Pallet
  • Trademark：DXY
  • Origin：China
  • HS Code：84213990
  • Production Capacity：100, 000m3,Month

Description

ItemOur products1Filter materialCordierite2Operating temperature limit (0C)10003Dimension (mm)Ø 150x150,  Ø 286x305, etc4Cell pitch (mm)100 cpsi5Cell wall thickness (mm)0.45-0.526Cell size (mm)2.02-2.097Mean pore size (um)8-138Porosity (gas pocket rate) %50-559Coefficient of thermal expansion1.6x10-610Softening temperature (0C)136011Compressive Strength (Mpa)Lengthwise direction10Lateral direction212Water absorption rate:35% ItemOur products1Filter materialCordierite2Operating temperature limit (0C)10003Dimension (mm)143.8x152.4 etc4Cell pitch (mm)200 cpsi5Cell wall thickness (mm)0.32-0.356Cell size (mm)1.45-1.487Mean pore size (um)8-138Porosity (gas pocket rate) %50-559Coefficient of thermal expansion1.5x10-610Softening temperature (0C)136011Compressive Strength (Mpa)Lengthwise direction>10.0Lateral direction>2.012Water absorption rate:38% Size(Diameter  ×  length)Cell densityShapemmInchesΦ 118.4 × 101.6Dia.4.66 × 4100/200CPSIRotundityΦ 118.4 × 152.4Dia.4.66 × 6100/200CPSIRotundityΦ 127 × 152.4Dia.5 × 6100/200CPSIRotundityΦ 144 × 101.6Dia.5.66 × 4100/200CPSIRotundityΦ 144 × 150Dia.5.66 × 5.9100/200CPSIRotundityΦ 144 × 152.4Dia.5.66 × 6100/200CPSIRotundityΦ 144 × 254Dia.5.66 × 10100/200CPSIRotundityΦ 150 × 150Dia.5.9 × 5.9100/200CPSIRotundityΦ 190 × 200Dia.7.48 × 7.87100/200CPSIRotundityΦ 190 × 203Dia.7.48 × 8100/200CPSIRotundityΦ 228 × 305Dia.8.97 × 12100/200CPSIRotundityΦ 240 × 100Dia.9.45 × 3.94100/200CPSIRotundityΦ 240 × 240Dia.9.45 × 9.45100/200CPSIRotundityΦ 240 × 305Dia.9.45 × 12100/200CPSIRotundityΦ 260 × 305Dia.10.23 × 12100/200CPSIRotundityΦ 267 × 305Dia.10.50 × 12100/200CPSIRotundityΦ 286 × 267Dia.11.26 × 10.50100/200CPSIRotundityΦ 286 × 305Dia.11.26 × 12100/200CPSIRotundityΦ 286 × 355Dia.11.26 × 13.97100/200CPSIRotundityΦ 286 × 381Dia.11.26 × 15100/200CPSIRotundity203.3 × 97 × 152.48 × 3.82 × 6100 CPSIRace track203.3 × 97 × 2548 × 3.82 × 10100 CPSIRace track188 × 103 × 1457.4 × 4.05 × 5.7100 CPSIRace track191 × 95 × 152.47.52 × 3.74 × 6100 CPSIRace track374 × 270 × 31714.72 × 10.62 × 12.48100 CPSIAssemble track
