Cordierite DPF Diesel Particulate Filter Honeycomb Ceramic Filter
Beihai Xiaoming International Import and Export Trading Co., Ltd.- Body Material：Ceramic
- Discharge Standard：Euro IV
- Certification：ISO9001, TS16949
- Component：Catalytic Converter
- Material：Cordierite, Sic
- Shape：Oval, Round, Racetrack
Base Info
- Model NO.：DPF
- Cell：100-600cpsi
- Usage：as Catalyst Used in Automobile,Motorcycle
- Transport Package：Wooden Box,Carton Box with Pallet
- Trademark：DXY
- Origin：China
- HS Code：84213990
- Production Capacity：100, 000pieces,Month
Description
Property (uncatalyzed)100/17 200/12 Cell density cpsi 100 200 cpscm 15.5 31.0 Wall thickness inch 0.017 0.012 mm 0.432 0.305 Open frontal area (OFA), % 34.5 34.5 Geometric surface area (GSA) Inch 2 33.3 47.0 m 2 /l 1.31 1.85 Hydraulic diameter Inch 0.083 0.059 mm 2.11 1.49 Modulus of rupture (psi/cpscm) 350 300 Porosity (%) 48 48 Coefficient of thermal expansion
10 2 cm/cm/ (20-800) --maximum average 5 5 Mean pore size (micron) 13 13 Melting temperature () 1460 1460
10 2 cm/cm/ (20-800) --maximum average
| Shape | Hole density (hole/in2) | Size (mm) | Size (inch) |
| Round | 100/200 CPSI | Φ 127 × 152.4 | 5 × 6 |
| Round | 100/200 CPSI | Φ 144 × 150 | 5.66 × 5.9 |
| Round | 100/200 CPSI | Φ 144 × 152.4 | 5.66 × 6 |
| Round | 100/200 CPSI | Φ 144 × 254 | 5.66 × 10 |
| Round | 100/200 CPSI | Φ 150 × 150 | 5.9 × 5.9 |
| Round | 100/200 CPSI | Φ 190 × 200 | 7.48 × 7.87 |
| Round | 100/200 CPSI | Φ 190 × 203 | 7.48 × 8 |
| Round | 100/200 CPSI | Φ 190 × 305 | 7.48 × 12 |
| Round | 100/200 CPSI | Φ 228 × 305 | 8.97 × 12 |
| Round | 100/200 CPSI | Φ 240 × 76.2 | 9.45 × 3 |
| Round | 100/200 CPSI | Φ 240 × 100 | 9.45 × 3.94 |
| Round | 100/200 CPSI | Φ 240 × 240 | 9.45 × 9.45 |
| Round | 100/200 CPSI | Φ 240 × 305 | 9.45 × 12 |
| Round | 100/200 CPSI | Φ 260 × 305 | 10.23 × 12 |
| Round | 100/200 CPSI | Φ 267 × 305 | 10.50 × 12 |
| Round | 100/200 CPSI | Φ 286 × 100 | 11.26 × 3.94 |
| Round | 100/200 CPSI | Φ 286 × 267 | 11.26 × 10.50 |
| Round | 100/200 CPSI | Φ 286 × 305 | 11.26 × 12 |
| Round | 100/200 CPSI | Φ 286 × 355 | 11.26 × 13.97 |
| Round | 100/200 CPSI | Φ 286 × 381 | 11.26 × 15 |
| Round | 100/200 CPSI | Φ 305 × 330 | 12 × 13 |
| Race track | 100 CPSI | Φ 188 × 103 × 145 | 7.4 × 4.05 × 5.7 |
| Assemble track | 100 CPSI | Φ 374 × 270 × 317 | 14.72 × 10.62 × 12.48 |
