• Model NO.：MHS
• Automobile Chassis Noise：The Brake Noise
• Component：Catalytic Converter
• Main Market：Europe
• Material：SS304, SS316, Fe-Cr-Al Alloy
• Application：as Catalyst Used in Automobile,Motorcycle
• Cell：100-600cpsi
• Thickness(mm)：0.04-0.1
• Width(mm)：10-250
• Max Working Temperature：1100°c
• Max Service Temperature：1250°c
• Transport Package：Wooden Box and Pallet,Packed as Customers′ Need
• Specification：all size
• Trademark：DXY
• Origin：China
• HS Code：84213990
• Production Capacity：100, 000pieces,Month

Basic Info.

Model NO. MHS Automobile Chassis Noise The Brake Noise Component Catalytic Converter Main Market Europe Material SS304, SS316, Fe-Cr-Al Alloy Application as Catalyst Used in Automobile/Motorcycle Cell 100-600cpsi Thickness(mm) 0.04-0.1 Width(mm) 10-250 Max Working Temperature 1100°c Max Service Temperature 1250°c Transport Package Wooden Box and Pallet/Packed as Customers′ Need Specification all size Trademark DXY Origin China HS Code 84213990 Production Capacity 100, 000pieces/Month

Product Description

Catalyst Honeycomb Metal Subsrate:
Metal Honeycomb Substrate Catalyst is made of catalyst platinum and palladium, these three precious metals to rhodium. When carbon monoxide, hydrocarbon and nitrogen gas through the catalyst, the activity will improve under high temperature. As results, carbon monoxide is oxidized carbon dioxide, hydrocarbons into water and carbon dioxide and nitrogen oxides reduction of nitrogen.

The material of outside shell is SUS441 and 444, the foil material of inside is OCr21Al6, and the thickness is 0. Imm. Compared to ceramic honeycomb substrate, metal honeycomb substrate has good heat conduction advantage. It can be made of concentric round metal substrate, also can be made of duboule's metal substrate.

Catalyst Carrier Honeycomb Metal Substrate:
*Can supply with Europe. II, III, IV, V Standard product
*Can supply samples for your testing
*Can supply SGS test or other test as you need
*Can supply various of type as you need
*Can supply top quality and competitive metal honeycomb substrate



Shape	Shell size(mm)	Core size(mm)	Cell density (CPSI)
Rotundity	Φ 30×22	Φ 28×20	100/200/300/400
Rotundity	Φ 35×20	Φ 33×20	100/200/300/400
Rotundity	Φ 35×30	Φ 33×30	100/200/300/400
Rotundity	Φ 35×40	Φ 33×40	100/200/300/400
Rotundity	Φ 35×50	Φ 33×50	100/200/300/400
Rotundity	Φ 35×60	Φ 33×60	100/200/300/400
Rotundity	Φ35 × 70/100/130	Φ33 × 60/90/120	100/200/300/400
Rotundity	Φ42 × 70/100/130	Φ40 × 60/90/120	100/200/300/400
Rotundity	Φ45 × 70/100/130	Φ43 × 60/90/120	100/200/300/400
Rotundity	Φ63,5 × 85/100/130	Φ60,5 × 74,5/90/120	200/300/400
Rotundity	Φ73 × 70/100/130 L	Φ70 × 60/90/120	200/300/400
Rotundity	Φ93 × 70/100/130	Φ90 × 60/90/120	200/300/400
Rotundity	Φ100,3 × 100/130	Φ98,3 × 90/120	600
Rotundity	Φ144 × 150/152,4	Φ142 × 140/142,4	200/300/400
Rotundity	Φ190 × 200	Φ188 × 190	200/300/400
Rotundity	Φ420 × 100/130	Φ416 × 90/120	300/400
Race track	123×63×85	120×60×75	200/300
Race track	123×63×100	120×60×90	200/300
Race track	78,5×52×104	76,5×50×90	200/300
