• Model NO.：OCC01
• Structure：Screw Type
• Cooling Fluid Type：Glycol
• Radiator Type：Cross-flow
• Radiator Core Type：Bar and Plate
• Water Temperature Sensor Type：Switch Type
• Cooling Fluid Brand：Great Wall
• Size：248*315*65
• Structure Material：Metal Material
• Application：Cooler
• Heat Transfer Surface：Plate Fin
• Transport Package：Wood Pallet
• Specification：SGS
• Trademark：ZRCOOLER
• Origin：China Jiangsu
• Production Capacity：10000PCS

Basic Info.

Model NO. OCC01 Structure Screw Type Cooling Fluid Type Glycol Radiator Type Cross-flow Radiator Core Type Bar and Plate Water Temperature Sensor Type Switch Type Cooling Fluid Brand Great Wall Size 248*315*65 Structure Material Metal Material Application Cooler Heat Transfer Surface Plate Fin Transport Package Wood Pallet Specification SGS Trademark ZRCOOLER Origin China Jiangsu Production Capacity 10000PCS

Product Description

This is our standard oil cooler from 5kw to 260kw with fan motor 12V/24V DC; Or 220V/380V AC or hydraulic motor

Features:
Bar & Plate Brazed Aluminum Core
Rugged, Lightweight and Compact.
Welded aluminum flange.
Available in 6 sizes to accommodate flow ratings of 50 to 600 gpm
220 or 380 volt AC fans
Both mobile and industrial applications
Customized units available
Ratings:
Maximum Working Pressure: 20bar
Ambient temperature: : 35
Hydraulic oil maximum inlet temperature: 70
Materials:
Cooler: Aluminum
Fan Guard: Plastic
Shroud: Powder Painted Iron
Fan Blade: Plastic

Material
core	Tank	Nose bar	Air fin/turbulator/End plate	connections	Mounting Brackets
Brzed aluminum bar and plate	5052 aluminum	3003 aluminum	3003 aluminum	aluminum	aluminum
