DPF Sic/Cordierite Honeycomb Ceramic for Exhaust System
Beihai Xiaoming International Import and Export Trading Co., Ltd.- Body Material：Ceramic
- Discharge Standard：Euro IV
- Certification：ISO9001, TS16949
- Noise Source：The Noise of Engine
- The Noise of Engine：Mechanical Noise
- Automobile Chassis Noise：The Brake Noise
Base Info
- Model NO.：DPF
- Component：Catalytic Converter
- Main Market：Southeast Asia
- Material：Cordierite
- Size：240*305mm, 320*430mm, 144*152.4mm etc
- Cpsi：100-600
- Usage：as Catalyst Used in Diesel Engine
- Transport Package：Wooden Box,Carton Box with Pallet
- Trademark：DXY
- Origin：China
- HS Code：84213990
- Production Capacity：100, 000pieces,Month
Description
ItemTechnical index Chemical Composition SiO2 50.9±1% AL2O3 35.2±1% MgO 13.9±1% Physical Properties Compression Strength in normal temperature ≥10Mpa Thermal expansion coefficient ≤1.2×10-6 /Degree C Wall thickness of hole density of 100 hole/ in2 0.42-0.50mm Wall thickness of hole density of 200 hole/ in2 0.32-0.40mm Apparent porosity ≥50% Average hole diameter 10-15 micron Highest Working Temperature 1400Degree C Soot-filtration efficiency ≥95%
