Diese Engine Valve for Cummins M11 Intake & Exhaust
Shijiazhuang Huacheng Automobile Accessories Co., Ltd.- Engine Type：Cummins
- Camshaft Layout：Mid Mounted
- Valve Layout：Top Mounted
- Component：Valve Assembly
- Intake：4926069
- Exhaust：4999616
Base Info
- Model NO.：M11
- Intake Material：4cr10si2mo
- Exhaust Material：21-8n+4cr9si2
- Transport Package：Box, Carton
- Specification：STD
- Trademark：HUACHENG
- Origin：Shijiazhuang of China
- HS Code：8409999990
- Production Capacity：100000
Description
Engine
Model
Description
Part number
Material
Size(mm) DΦ X° d Φ L
CUMMINSNT855 Intake 135957 4Cr9Si2 47.5 60° 11.5 179.42 Exhaust 145701 21-4N+4Cr9Si2 47.5 60° 11.5 179.42 6BT Intake 3920867 4Cr10Si2Mo 45 60° 8 129 Exhaust 3920868 21-4NWNb+4Cr9Si2 42 45° 8 129 6CT Intake C3924492 4Cr10Si2Mo 52 60° 9.5 151 Exhaust C3921444 21-4NWNb+4Cr9Si2 46 45° 9.5 151 ISL Intake 4981794 21-4N+4Cr9Si2 38 60° 8 137.75 Exhaust 4981795 21-4NWNb+4Cr9Si2 38 45° 8 137.77 ISDE Intake C3940735 4Cr10Si2Mo 33 60° 7 124.6 Exhaust C3940734 21-4NWNb+4Cr9Si2 33 45° 7 124.45 ISF Intake 5261320 4Cr10Si2Mo 32.7 60° 6 106.18 Exhaust 5256949 21-4NWNb+4Cr9Si2 29 45° 6 106.72 ISM11 Intake 4926069 4Cr10Si2Mo 42.5 60° 9.62 195.5 Exhaust 4999616 23-8N+4Cr9Si2 42.5 60° 9.62 195.5 K38 Intake 3052820 4Cr10Si2Mo 56.5 60° 12.5 190 Exhaust 3088389 Inconel751+4Cr10Si2Mo 56.5 60° 12.5 190 K19 Intake 2072411 4Cr10Si2Mo 56.5 60° 12.5 190 Exhaust 3035110 23-8N+4Cr9Si2 56.5 60° 12.5 190
