for Denso Iridium Spark Plug Sc20hr11 for Corolla/Zre120 OEM: 90919-01253
QINGDAO GUARDX IMP & EXP CO., LTD.- Component：Spark Plug
- Certification：TS16949, ISO9001: 2000, CE, CSA
Base Info
- Model NO.：90919-01253
- Transport Package：Export Package
- Specification：4477 ITR6F13
- Trademark：Guardx
- Origin：China
- HS Code：8409919990
- Production Capacity：500000,PCS
Description
Thread
M14x1.25
Reach
19 mm
Hex
16mm
Seat Type
Flat
Gap
1.1mm
Heat Range
6
Electrode Type
J Type
Resistor or Non-Resistor
Resistor
Electrode Enhancements
Iridium and platinum electrode
Motorcycle spark plug specification
Thread | M10*1; M12*1.25; M14*1.25 |
Reach | 12.7mm; 19mm; |
Hex | 16mm; 17.5mm; 20.8mm; |
Seat type | Flat |
Gap | 0.9mm;1.1mm; 1.3mm |
Heat Range | 5;6;7 |
Electrode Type | J Type |
Resistor or Non-Resistor | With resistor; Without resistor |
Electrode Enhancements | Iridium and platinum electrode;cooper core electrode |
Small engine spark plug specification
Thread
M10x1/M12x1.25/M14x1.25
Reach
9.5mm/12.7 mm/ 19 mm/ 19 mm
Hex
16 mm/17.5 mm/19mm/20.8 mm
Seat Type
Flat
Gap
1.1 mm
Heat Range
6/7/8
Electrode Type
J Type
Resistor or Non-Resistor
Non Resistor/ Resistor
Electrode Enhancements
Copper Core Electrode
