Honeycomb Ceramic Diesel Particulate Filter
Beihai Xiaoming International Import and Export Trading Co., Ltd.- Type：Catalytic Converter
- Body Material：Aluminium
- Discharge Standard：Euro IV
- Certification：ISO9001, TS16949
- Noise Source：The Noise of Engine
- The Noise of Engine：Mechanical Noise
Base Info
- Model NO.：DPF
- Automobile Chassis Noise：The Brake Noise
- Component：Catalytic Converter
- Main Market：Europe
- Specification：286*305, 286*100, 144*152.4, 240*305 etc
- Cell：100-200cpsi
- Color：White,Green
- Application：as Catalyst Used in Diesel Engine
- Transport Package：Wooden Box,Carton Box with Pallet
- Trademark：DXY
- Origin：China
- HS Code：842139900
- Production Capacity：100, 000m3,Month
Description
ItemDiesel particulate filter 1 Filter material Cordierite and Silicon carbide 2 Operating temperature limit (Degree C) 1000 3 Dimension (mm) Ø144x150,Ø144x152.4,Ø150x150,Ø190x200,Ø190x203, Ø240x240,Ø240x305 Ø260x305, Ø267x305, Ø286x305, Ø286x355,Ø374x270x317 4 Cell pitch (mm) 100 cpsi 5 Cell wall thickness (mm) 0.45-0.52 6 Cell size (mm) 2.02-2.09 7 Mean pore size (um) 8-13 8 Porosity (gas pocket rate) % 50-55 9 Coefficient of thermal expansion 1.6x10-6 10 Softening temperature (Degree) 1360 11 Compressive Strength (Mpa) Lengthwise direction 10 Lateral direction 2 12 Water absorption rate: 35% 100/17 200/12 Cell density cpsi 100 200 cpscm 15.5 31.0 Wall thickness inch 0.017 0.012 mm 0.432 0.305 Open frontal area (OFA), % 34.5 34.5 Geometric surface area (GSA) Inch2 33.3 47.0 m2/l 1.31 1.85 Hydraulic diameter Inch 0.083 0.059 mm 2.11 1.49 Modulus of rupture (psi/cpscm) 350 300 Porosity (%) 48 48 Coefficient of thermal expansion
102 cm/cm/ (20-800) --maximum average 5 5 Mean pore size (micron) 13 13 Melting temperature (Degree C) 1460 1460
102 cm/cm/ (20-800) --maximum average
| Component | Unit | Data | Component | Unit | Data |
| SiO2 | wt% | 48-51 | Fe2O3 | wt% | <0.5 |
| Al2O3 | wt% | 31-34 | Na2O | wt% | <0.5 |
| MgO | wt% | 14-16 | K2O | wt% | <0.5 |
