• Model NO.：C160
• Average Lead Time：1-3 Months
• Import & Export Mode：Have Own Export License
• Transport Package：Plastic Bag, Carton Box,Foam
• Specification：As Customer Required
• Trademark：As Customer Required
• Origin：China
• HS Code：8414803090
• Production Capacity：100000

Basic Info.

Model NO. C160 Average Lead Time 1-3 Months Import & Export Mode Have Own Export License Transport Package Plastic Bag/ Carton Box/Foam Specification As Customer Required Trademark As Customer Required Origin China HS Code 8414803090 Production Capacity 100000

Product Description



• BRAND NEW TURBOCHARGER BILLET COMPRESSOR WHEEL

  This is a BRAND NEW TURBOCHARGER BILLET COMPRESSOR WHEEL. This is an exact, direct fit replacement turbo compressor wheel.

  Fits the following:

  Part Number: MFSC610C, C610
  Interchangeable Number: NH265520
  Description: Billet Compressor Wheel

  BCCW Blades: 6+6
  Nose Diameter: 15.09 mm
  KTS Inducer: 46.80 mm
  KTS Base Exducer: 69.00 mm KTS Tapered Tip Exducer:
  KTS Tip Height: 5.53 mm Superback: 4.20 mm
  Overall Height: 36.40 mm
  Bore Size: 7.10 mm
  Trailing Angle: 60°
  Cutback: 3.00 mm
  SP Height Angle:
  BCCW Blade Height: 29.07 mm Splitter Height:
  Tapered Tip Angle: 0°

  Racing or Non-Racing: Non-Racing
  STD or Custom Size: STD
  Bore Type: Through
  OE or Custom Compressor House Fitment: OE Rotation: Forward

  Fit for Turbo Part Numbers (V-Code):
  VA240086, VB240107, VC240080, VC240101, VD240083, VD240090

  Fit for Turbo Part Numbers (Short Spec):
  MYAV, MYAV0310, MYBC, MYBF, MYDA, MYDH, MYDN, 4715

  Fit for OEM Numbers:
  11917218010, 11917218011, 11917218030, 11917318040, 11917318041, 11917518030, 11917518031, 11919518020, 11919518021, 11919518030, 11919518031, 119172-18010, 119172-18011, 119172-18030, 119173-13041, 119173-18040, 119175-18030, 119175- 18031, 119195-18020, 119195-18021, 119195-18030, 1-19195-18030, 119195-18031, 1- 19195-18031, 6T-583

  Fit for Turbo Models:
  RHC61W, RHC61W-1036P16NWBRLL4715CC, RHC61W-1036P18NWBRLL4715CC, RHC61W-1063P16NWBRLL4715CCZ, RHC61W-1063P18NWBRLL4715CC, RHC61W- 1183P18NWBRLL4715CC, RHC61W-943P18NWBRLL4715CC

  Fit for Applications:
  1987-01 Yanmar Marine with 4LH-HTE Engine
  1995-98 Yanmar Marine with 4.0L 4LH-STE Diesel Engine
  1998-01 Yanmar Marine with 3.5L 4LHA-STE, STE-4LHA, 4LHA-STZE-YA Diesel Engine 2000-01 Yanmar Marine with 3.5L 4LHA-DTZE, 4LHA-DTE, 4LHA-DTP, 4LHA-DT(Z)E(P) Diesel Engine
  2000-02 Yanmar Marine with 4.0L 4LHA-HTE, 4LHAHTE Diesel Engine
  Yanmar Marine with 4.0L 4LH-ST, 4LH-WST, 4LH-WSTZAY Diesel Engine

  *Important* Please use the above information to determine if the part(s) in this listing fit your vehicle. The most reliable way to make sure the model of turbo is Lnding the part number from the nameplate of your old turbo.

  Any questions or concerns, please feel free to email or call us.
