• Model NO.：Sanhe CS HC
• Automobile Chassis Noise：Transmission Noise
• Component：Exhaust Tail Pipe
• Main Market：Europe
• Soften Temperature：≤1410
• Water-Absorbingrate：24±4%
• Thermal Shock Resistance：≤550ºC
• Cordierite Crystal Content：≥90
• Mesh Number：200mesh, 300mesh, 400mesh
• Open Area：≥70%
• Volume Weight：≤460g,L
• Wall Thickness：0.17mm
• Outside Dimension：25-100mm, 100-15mm
• Transport Package：Hard Carton or Wooden Carton with Pallet
• Specification：Cordierite,Alumuina, Carbide
• Trademark：Sanhe
• Origin：Jiangxi Province, China
• HS Code：6909110000
• Production Capacity：800, 00pieces,Month

NameIndexTolerance RangeWall Thickness0.17mm0.03mm-0.02mmVolume Weight≤460G/L±60G/LOutside Dimension25-100mm±1mm100-15mm≤±1%Perpendicularity ≤1.0%(height)Depth of Parallelism ≤1.0%(height)Mesh Number200mesh, 300mesh, 400mesh  Cell Density(CPSI):7~400ItemSectional Dimension(mm)Area of Section(mm2)Height(mm)150*502500The height can be designed by customer250*5025003100*100100004150*15022500
Physical and Chemical Properties:NameUnitIndexChemical CompositionAl2O3%35.1±1.6MgO%13.5±1.5SiO2%50.0±1.8Compression StrengthA-axisMpa≥15.0B-axisMpa≥3.0C-axisMpa≥0.15Coefficient of Thermal Expansion (20-800ºC)ºC≤1.5*10-6Soften TemperatureºC≤1410Thermal Shock ResistanceºC≤550ºCWater-absorbingrate%24±4%Cordierite Crystal Content%≥90Open Area%≥70%


 About us
     Pingxiang Sanhe Ceramics Co., Ltd. lies in Pingxiang city, Jiangxi province, which belongs to one of the five ceramic production export bases in China. The company is a private technology share ceramics manufacturing enterprise founded in 2004. We specialize in honeycomb ceramic plates, honeycomb ceramics heat accumulators, honeycomb ceramic honeycomb substrates, ceramic foam filter and other producing energy conservation and environmental protection series ceramic products.
     Sanhe Ceramics has successfully passed all kinds of certifications such as ISO9001 ISO14001, OHSAS18001 and so on, as well as established perfect quality control system and quality assessment system. Our company has been strictly controlled the whole manufactring system from production planning, processing control to maintenance of equipment as well as from raw material warehousing to quality test of finished products, We offer Stable and qualified products to customers from all over the world.
     Sanhe ceramics Co.,Ltd keeps the faith of "First impression is the last impression" and provides the best quality and comfortable service to all the buyers, No matter the deal is big or small, we are warmly welcome your coorperation. Any inquiries pls contact with us!
