BV39 Turbo 54399880022 038253010d Turbocharger

Refone Auto Power Co., Ltd.
  • Type：Turbocharger
  • Body Material：Iron
  • Certification：ISO9001, CE
  • Part Number：54359880022
  • OE Number：038253014G
  • Shipping：TNT,UPS,FedEx,DHL,Express, etc.

Base Info

  • Model NO.：BV39
  • Engine：Bjb, Bkc, Avq
  • Bearing Housing：54391504013
  • Turbine Wheel：54391205011
  • Heat Shield Number：54391652001
  • Back Plate：54431523000
  • Displacement：1.9L, 1896 CCM, 4 Cyl, Diesel
  • Turbine Housing Ar：Vtg
  • Transport Package：1. Mold Foam 2. Plastic Bag 3. Strong Carton
  • Specification：ISO9001
  • Trademark：REFONE
  • Origin：China
  • HS Code：8414803000
  • Production Capacity：20000PCS,Year

Description

Basic Info.

Model NO. BV39 Engine Bjb, Bkc, Avq Bearing Housing 54391504013 Turbine Wheel 54391205011 Heat Shield Number 54391652001 Back Plate 54431523000 Displacement 1.9L, 1896 CCM, 4 Cyl, Diesel Turbine Housing Ar Vtg Transport Package 1. Mold Foam 2. Plastic Bag 3. Strong Carton Specification ISO9001 Trademark REFONE Origin China HS Code 8414803000 Production Capacity 20000PCS/Year

Product Description

BV39 Turbo 54399880022 038253010d Turbocharger

BV39 Turbo 54399880022 038253010D Turbocharger

Product details
Part Number54399880022
Previous Version5439-988-0022, 5439 988 0022, 54399880011
OE number038253014G, 038253010D, 038253056E
Year2002-12
DescriptionAudi, Volkswagen
Manufacturer Part Number54399700022, 5439-970-0022, 54399700011, 54399710022
CHRAIN STOCK,
Turbo ModelBV39-1873CCB426.10AVAXC
EngineBJB, BKC, AVQ
Displacement1.9L, 1896 ccm, 4 CYL, Diesel
KW77/105
RPM Max4000
Angle α (compressor housing)196
Angle β (turbine housing)90
Bearing Housing54391504013
Turbine Wheel54391205011
Comp. Wheel54431232012
Back plate54431523000
Heat shield Number54391652001



Turbine Housing ARVTG

Applications

2004-07 Audi A3 TDI with BJB, BKC, AVQ Engine
2007 Seat Altea , Leon, Toledo with BJB, BKC, AVQ Engine
2007 Skoda Octavia, Fabia with BJB, BKC, AVQ Engine
Volkswagen Touran with BJB, BKC, AVQ Engine
2004-11 Volkswagen Golf V TDI with BJB, BKC, AVQ Engine
2002-12 Volkswagen Touran TDI with BJB, BKC, AVQ Engine
2007- Volkswagen Caddy with BJB, BKC, AVQ Engine
SPECS
BV39 Turbo 54399880022 038253010d Turbocharger

1. One year quality warranty
2. Hot selling&fast delivery
3. High quality
4. Sample order is acceptable

OUR SERVICES
BV39 Turbo 54399880022 038253010d Turbocharger

1.12 monthes Quality Warranty.
2. Sample Order is Acceptable. 3. After sale Service: Take photos Send for testing Send new turbo to customer.
3. Design new types according to customer's requirements.
Later, I will send the pictures to you by E-mail, then you can check the phots to judge whether it is the same with your turbos
RHB5897365948034123AIsuzu
RHB58944739540
 		Isuzu 100ps
RHC71-14400-2100
 		Ex200-1 6BDIT
RHF4VV14
 		Mercedes-PKW Sprinter II 211CDI/311CDI/411CDI/511CDI
RHF4HVG420014


RHF4VVJ32
 		Mazda 6 CiTD
RHF4VVJ33WL8413700AMAZDA
RHF530470878973311850Isuzu
RHF5897139743
 		Isuzu
RHF5897365948034123AIsuzu
RHF5897240101VA20037IHI VIDA--Isuzu Pick-up,4JAIT,2.5L
RHF5BVH6600128970863433ISUZU/Opel FRONTERA
IHIVVP1507/VJ4000029622526980Citroen Xsara/Picasso
IHIVA70F40001035242096FCherokee 2.5CRO
RHB31VZ9 NB130042/VA110023/VA110065/VB110023/
VB110065/VC110023/VC110065/VD110023/
VD110065/VE110065/VF110065
 		SUZUKI Jimmy 500-660cc engine,or for motorcycle and dune buggy modification purpose
RHB31VZ21 VE110069/VJ110069
 		SUZUKI Jimmy 500-660cc engine,or for motorcycle and dune buggy modification purpose
